Goojung TCS Total Concentration System
The Evatros Mini Evaporator is a gas blowing type of sample pre-treatment instrument capable of up to 24 sample preparation. Each of the 24 nozzles can be independently utilised and constantly supply gas without variation of flow and pressure regardless of the number of nozzles used.
A unique design of terraced structure of the aluminum heating block with slit enables a user to comfortably monitor the progress of sample concentration.
Model | Evatros Mini |
Nozzle | 24 nozzles with 5 holes - independent control of flow rate and pressure |
Test tubes | Round block - 24 holes, 16.3mm - 10~16mL (Standard) |
Minimum gas inlet | Nitrogen Gas 60L/min @30psi, Dry Air 120L/min @30psi |
Heating block temp | Ambient ~ 80℃ |
Electrical requirements | 220[V], 50/60[Hz], 2[A] |
Dimensions (cm) | 69(H)x47(W)x27.5(D) |
Weight | 27.4KG |
