Berghof High Pressure Reactors
BERGHIGHPRESSURE
Enquire about this item
Buy Berghof High Pressure Reactors in NZ.

Modularity and flexibility in the synthesis

The next generation

The next generation stands for both the expansion of our product line to include smaller volumes (down to 25ml) as well as for more flexibility of essential product features. For the first time, all high pressure reactors are now available as pure stainless steel or pressure reactors, as well as with complete PTFE lining; a feature unique to Berghof. All fittings are also available in these materials.

Greater value

Each pressure reactor is the product our experience in pressure vessel design and construction, gained in over 25 years. This is "added value" you can comprehend:

  • technically safe and reliable
  • economical in use
  • simple with regard to handling


High Pressure Reactor BR-25, the "Little One"

25 ml, 40 ml, 200 bar/2,900 psi, up to 300°C

The high pressure reactor is available in Stainless Steel SS 316Tl, Hastelloy C-4 , or Stainless Steel SS 316Tl with a PTFE insert and with no lid liner.

The useable pressure reactor volume can be varied by the employment of different reactor vessels ranging from 25 ml to 40 ml. Smaller volumes are available on request.

To close the pressure reactor, the vessel is simply screwed into the lid by hand.

The pressure vessel is sealed by means of a conical flange lock and an O-ring made of PTFE, Viton ® , or Kalrez ® .

The matching fittings sets are available in Stainless Steel SS 316Tl or Hastelloy C-4.


High Pressure Reactor BR-100, the "Handy One"

75 ml, 100 ml, 150 ml, 200 ml, 200 bar / 2,900 psi, up to 300°C

The high pressure reactor is available in Stainless Steel SS 316Tl, Hastelloy C-4, or Stainless Steel SS 316Tl with a PTFE lining closed on all sides.

The pressure reactor is locked with a quick-lock chain that is manually applied, without the need for tools.

The pressure vessel is sealed by means of a conical flange lock and an O-ring made of PTFE, Viton ® , or Kalrez ® .

The matching fittings sets are available in Stainless Steel SS 316Tl or in Hastelloy C-4.

High Pressure Reactor BR-300, the "Universal One"

300 ml, 350 ml, 500 ml, 600 ml, 700ml, 900 ml,  200 bar / 2,900 psi, up to 300°C

The high pressure reactor is available in Stainless Steel SS 316Tl, Hastelloy C-4, or Stainless Steel SS 316Tl with a PTFE lining closed on all sides.

The pressure reactor is locked with a quick-lock clamp that is manually applied, without the need for tools.

The pressure vessel is sealed by means of a conical flange lock and an O-ring made of PTFE, Viton ® or Kalrez ® .

The matching fittings sets are available in Stainless Steel SS 316Tl or in Hastelloy C-4.



High Pressure Reactor BR-1000, the "Big One"

1,000 ml, 1,100 ml, 1,500 ml, 1,700 ml, 2,000 ml, 2,300 ml,  200 bar / 2,900 psi, up to 300°C

The high pressure reactor is available in Stainless Steel SS 316Tl,  Hastelloy C-4 or Stainless Steel SS 316Tl with a PTFE lining closed on all sides.

The pressure reactor is locked with a quick-lock chain that is manually applied, without the need for tools.

The pressure vessel is sealed by means of a conical flange lock and an O-ring made of PTFE, Viton ® or Kalrez ® .

The matching fittings sets are available in Stainless Steel SS 316Tl or in Hastelloy C-4.
