The Pump 11 Elite Series of syringe pumps expands its capabilities to satisfy your experimental requirements. These compact syringe pumps carry on the tradition as the premiere workhorse infusion pump, offering unparalleled ease of use with a high resolution touch screen with intuitive icon interface.
These innovative syringe pumps have a new mechanism that includes a tight gripping, more secure syringe clamp for syringes ranging from 0.5 ul to 60 ml (single syringe) and 0.5 ul to 10 ml (dual syringe). The Pump 11 Elite Series offers enhanced flow performance with high accuracy and smooth flow from 1.28 pl/min to 88.28 ml/min.
The Pump 11 Elite Infusion Only Models are available in single or dual syringe rack configurations. These pumps have advanced connectivity with a USB serial port for computer control and footswitch connection for stop/start control (footswitch sold separately).
| Specifications | 70-4500 | 70-4501 |
|---|---|---|
| Accuracy | ±0.5% | ±0.5% |
| Classification | Class I | Class I |
| Dimensions Control Box | 9.0 x 7.0 x 6.0 in (22.6 x 17.78 x 15.0 cm) |
|
| Display | 4.3" WQVGA TFT Color Display with Touchpad | 4.3" WQVGA TFT Color Display with Touchpad |
| Drive Motor | 0.9° Stepper Motor | 0.9° Stepper Motor |
| Environmental Humidity | 20% to 80% RH, non condensing | 20% to 80% RH, non condensing |
| Environmental Operating Temperature | 40°F to 104°F (4°C to 40°C) | 40°F to 104°F (4°C to 40°C) |
| Environmental Storage Temperature | 14°F to 158°F (-10°C to 70°C) | 14°F to 158°F (-10°C to 70°C) |
| Flow Rate Maximum | 88.28 ml/min using 60 ml syringe | 31.97 ml/min using 10 ml syringe |
| Flow Rate Minimum | 1.28 pl/min using 0.5 µl syringe | 1.28 pl/min using 0.5 µl syringe |
| I O TTL Connectors | 15 pin D-Sub Connector | 15 pin D-Sub Connector |
| Input Power | 12-30 VDC | 12-30 VDC |
| Installation Category | II | II |
| Max Linear Force | 35 lb @ 100% Force Selection | 35 lb @ 100% Force Selection |
| Mode of Operation | Continuous | Continuous |
| Motor Drive Control | Microprocessor with 1/16 microstepping | Microprocessor with 1/16 microstepping |
| Net Weight | 4.6 lb (2.1 kg) | 4.6 lb (2.1 kg) |
| No of Syringes | 1 | 2 |
| Non Volatile Memory | Storage of all settings | Storage of all settings |
| Number of Microsteps per one rev of Lead Screw | 15,360 | 15,360 |
| Pollution Degree | 1 | 1 |
| Pump Configuration | Standard | Standard |
| Pump Function | Infusion Only | Infusion Only |
| Pusher Travel Rate Maximum | 159.8 mm/min | 159.8 mm/min |
| Pusher Travel Rate Minimum | 0.18 µm/min | 0.18 µm/min |
| RS 232 Connectors | optional RJ-11 | optional RJ-11 |
| Regulatory Certifications | CE, UL, CSA, CB Scheme, EU RoHS | CE, UL, CSA, CB Scheme, EU RoHS |
| Step Rate Maximum | 26 µsec/µstep | 26 µsec/µstep |
| Step Rate Minimum | 27.5 sec/µstep | 27.5 sec/µstep |
| Syringe Size Maximum | 60 ml | 10 ml |
| Syringe Size Minimum | 0.5 µl | 0.5 µl |
| USB Connectors | Type B | Type B |
| Voltage Range | 100-240 VAC, 50/60 Hz | 100-240 VAC, 50/60 Hz |
