FoodLab

The Analysis of Food with CDR Food Lab Systems

CDR FoodLab Touch enables the user to control the quality of food like milk, cheeses and other dairy products, eggs, egg products and egg derivatives, tomato and vegetable purees, fats and oils.

It is used worldwide not only in laboratories and production lines in the food industry, but also in small cheese factories, dairy farms, cattle breeding farms, egg producers, and testing laboratories.

The CDR FoodLab system

• A spectrophotometric analyser that use LEDs, instead of usual tungsten lamps, 4 reading cells and 16 incubation cells thermostated at 37° C.
• "Step by step" built-in guide during the analysis procedure.
• A Kit of pre-vialed, disposable dedicated reagents with a low toxicity developed by the research laboratories of CDR and a 12-month shelf-life, in packages of 10 tests


Accessories:

• Pipettes to simplify the collection of the samples.
• Cold Extraction System to extract, by a simple mechanical treatment, the oil to analyse from drupes, nuts or finished products, like bakery products or creams. It does not involve the use of toxic solvents.

Easy to use

The system is designed to be used by anyone, without the support of specialised technical staff.

The analysis methods are easier than traditional ones and can be performed in just a few steps:

• Adding the sample volume to the pre-vialed reagent.
• Following the displayed instructions and if there is ever any doubt, the HELP function will lead you through the process.
• Results are automatically calculated, displayed and printed.

Reliable

This measuring system owes its sensitivity, accuracy and reliability to the photometric technology based on LED luminous sources.

The results of the analyses are correlated with reference methods.

Reduced testing times

It is possible to analyse 16 samples at the same time and to constantly monitor the production process, obtaining exact and accurate answers in just a few minutes.

The multitasking mode allows the user to manage the determinations of several analytical parameters at the same time. It allows the system to process one analysis and to start another one at the same time, with the option to return to the first one anytime.

The Advantages of the CDR FoodLab systems

In conclusion, here is how CDR FoodLab systems simplify and support food quality control:

• Ease of use - no skilled staff necessary; moreover the "step by step" guide assists the operator in case of uncertainty about the analysis method procedure;
• Utilisation of simple and optimised methods, rapid to perform, without risks, without waste and without the need of a specially equipped laboratory;
• Removes the necessity to engage an external laboratory;
• Allows you to make rapid and safe decisions: in a few minutes you obtain reliable results on your samples;
• The system gives accurate results, verified by the correlation curves and the conformity with reference chemical analysis methods;
• The system performs a complete range of analyses for the control of the food production process;
• Small size dimensions, compact and does not require maintainance: the system is a spectrophotometer fitting the analytical needs of food producers.


For more information or a quote, please contact us

Analysis CDR FoodLab systems can perform the tests in just a few minutes and do not require the samples to be pre-processed. Milk & Dairy Products L-Lactic acid in milk, cheese, cream Milk Urea Nitrogen (MUN) in milk Lactose in milk Ammonia in milk, cream, cheese Chloride in milk, cheese, aqueous solutions Alkaline phosphatase (ALP) of cow's milk Hydrogen peroxide in milk ­-fructosil-lysine (Furosine) in milk Peroxidase (POD) in milk Glucose in UHT milk Acidity in butter, margarine and cream Peroxide value in butter, margarine and cream Vegetable Puree & Tomato L - Lactic acid vegetable puree and Tomato Lactic acid (D + L) vegetable puree and Tomato Glucose in tomato Chloride in sauces Egg / Egg Products Butyric acid L-lactic acid Cholesterol Colour Total Acidity Xanthophylls Fats & Oils Free Fatty Acids (FFA) in edible fats, oils, butter, margarine and cream Peroxide Value in edible fats, oils, butter, margarine and cream Soaps in edible fats, oils and cream Polyphenols/Oil Stability Index (OSI) in olive oil p-Anisidine Value in edible fats and oils Iodine value only in palm oil

Analytical Kits Milk Analysis Number of Tests Code Range Milk Urea Nitrogen (MUN) 10 *300004 5 100 mg/dL 100 *300000 Ammonia 10 *300054 1 80 ppM 100 *300050 Chloride 10 *300100 50 400 mg/dL 100 *300104 L-Lactic Acid 20 *300076 2 200 ppM 100 *300075 Hydrogen Peroxide 10 *300328 1.5 25 ppM 100 *300325 Alkaline Phosphatase (ALP) "Cow's milk" 10 *300228 0.1 - 5 U/L 100 *300225 έ-fructosil-lysine 10 *300404 (10 - 1000) delta x 1000 100 *300400 Peroxidase 20 *300528 0.01 50 mEqO2/Kg 100 *300525 Lactose in Milk 10 *300010 0.1 - 5.5 %lactose 100 *300015 Glucose in UHT Milk 10 - 100 - ­Acidity 10 - 100 - Peroxidase Value 10 - 100 - Cheese Analysis Number of Tests Code Range Chloride in Aqueous Solutions 10 *300028 0.01-50 g/dL 100 *300385 Chlorides in Cheese 10 *300204 0.02 7 g% 100 *300200 Ammonia 10 *300054 1 80 ppM 100 *300050 L-Lactic Acid in Cheese 100 *300375 0.01-1.75 g% Egg Analysis Number of Tests Code Range L-Lactic Acid in Egg 20 *300388 10 10.000 ppM 100 *300385 D-3-hydroxybutyric Acid 10 *300426 0.5-15 ppM (mg/Kg) 100 *300420 ­Cholesterol 100 *300395 25 1450 mg/100g Colour 10 *300295 1,0 180,0 ppm 100 *300290 Total Acidity 10 *300241  1 - 10 degree 100 *300240 Xanthophylls 50 *300220 1,0 180,0 g/Kg Vegetable Puree & Tomato Number of Tests Code Range ­L-Lactic Acid in Vegetable Puree & Tomato 20 *300251 5 2100 ppM 100 *300250 Chloride in Sauces 10 *300204 0.02 7 g% 100 *300200 Glucose in Tomato 100 *300450 0.01 - 10 g/100 g glucose Lactic Acid (D+L) 10 - 100 - Fats & Oils Analysis Number of Tests Code Range ­Free Fatty Acid (FFA) 10 *300128 0.01 3.5% ac. Oleico

Technical Specifications of CDR FoodLab Systems The system: 37° C controlled temperature photometer Photometric module: 8 different wavelengths in 4 reading cells Incubation module: 37°C thermostat block with 16 positions Display: Touch model: 5,7 TFT color LCD touchscreen Connectivity: Touch model: 2 USB 2.0 ports, 1 USB port type B for technical service and PC connection, 1 Ethernet port (LAN). Internal Storage: 4 GB internal memory to store the performed tests Database format: CSV and XML file, compatible with all formats of database (e.g.: xls, SQL) Printer: Graphic printer on board 80mm width Weight: Touch model: 2,80 Kg Dimensions: Touch model: 32 cm x 29,5 cm x 13 cm (L x D x H) Power Supply: Touch model: external power supply AC/DC Prim. voltage:100 - 250V, 47 - 63 Hz, 0,8 A Sec. voltage 24V, 1,4 VA, max.: 3,0 A Environmental conditions for operation: the analyser and its equipment work at room temperature, from 12°C to 35°C and relative humididty from 20% to 80% not condensed.
